Safe state machines with Effect.ts and XState

Of all the theoretical concepts taught in my undergraduate computer science program, finite state machines (FSMs) are the one that has proved most useful in my professional work. At its core, a FSM answers two questions:

What state you're in
What states you can go to

More formally, a FSM is defined as a quintuple $\left( \Sigma, S, s_0, \delta, F \right)$ , where:

$\Sigma :=$ the input alphabet, the finite set of symbols the machine can be fed
$S :=$ a finite, non-empty set of states
$s_0 :=$ the initial state, where $s_0 \in S$
$\delta :=$ the transition function, where $\delta : S \times \Sigma \rightarrow S$
$F :=$ the possibly empty set of terminal states, where $F \subseteq S$

That's the same two questions written down. $S$ and $s_0$ answer what state you're in, $\delta$ answers what states you can go to, $\Sigma$ names the things that can happen, and $F$ says which states -- if any -- count as an ending.

The detail worth pausing on is that $\delta$ is a total function: it is defined for every pair in $S \times \Sigma$ , which means no event can arrive without an answer for it. That property is the whole reason this post exists, and it is the first thing a hand-rolled state machine throws away.

An example

Imagine the transport controls on a media player -- the three buttons every audio API has ever shipped. The player is stopped, playing, or paused, and the only things we can do to it are $\texttt{PLAY}$ , $\texttt{PAUSE}$ , and $\texttt{STOP}$ . That is the entire machine, and there is nothing else to know about it.

We can represent this as a FSM!

$\Sigma := \lbrace \texttt{PLAY}, \texttt{PAUSE}, \texttt{STOP} \rbrace$
$S := \lbrace \texttt{STOPPED}, \texttt{PLAYING}, \texttt{PAUSED} \rbrace$
$s_0 := \texttt{STOPPED}$
$F := \emptyset$

$F$ is empty because a player is an ongoing service -- it never stops, so no state is an ending. $\texttt{STOPPED}$ looks like one, but we can always leave it by playing again. Terminal states earn their keep when you want to ask "did this input end up somewhere acceptable?" In this example, though, all states are acceptable.

That leaves $\delta$ :

$\delta$	$\texttt{PLAY}$	$\texttt{PAUSE}$	$\texttt{STOP}$
$\texttt{STOPPED}$	$\texttt{PLAYING}$	$\texttt{STOPPED}$	$\texttt{STOPPED}$
$\texttt{PLAYING}$	$\texttt{PLAYING}$	$\texttt{PAUSED}$	$\texttt{STOPPED}$
$\texttt{PAUSED}$	$\texttt{PLAYING}$	$\texttt{PAUSED}$	$\texttt{STOPPED}$

It looks more complicated than it is. The rows correspond to our current state, and the values in each column tell us our next state (the value of the column) if we encounter some input (the column).

For example, if we are $\texttt{PLAYING}$ , the rules according to the table are:

If we $\texttt{PLAY}$ , we should keep $\texttt{PLAYING}$
If we $\texttt{PAUSE}$ , we should be $\texttt{PAUSED}$
If we $\texttt{STOP}$ , we should be $\texttt{STOPPED}$

This FSM can be represented visually with a flow chart, where each node is some state $\left(s \in S \right)$ and each directed edge is a transition according to our function $\delta : S \times \Sigma \rightarrow S$ :

Idle

import { createActor } from "xstate";
import { renderMachineFlow } from "@pg/flow";
import { player } from "./machine.ts";

export default function main(target: HTMLElement): () => void {
  const actor = createActor(player);
  const stop = renderMachineFlow(target, { machine: player, actor });

  const onClick = (event: Event) => {
    const type = (event.target as HTMLElement).dataset?.send;
    if (type === "PLAY" || type === "PAUSE" || type === "STOP") {
      actor.send({ type });
    }
  };
  target.addEventListener("click", onClick);

  return () => {
    target.removeEventListener("click", onClick);
    stop();
  };
}

Doing it by hand

Nine cells is not a lot to write down, and the first attempt usually doesn't try to. It reaches for one boolean per thing that feels like a mode:

Idle

// Two booleans, three states. The intended encoding, written out:
const NAMES: Record<string, string> = {
  "false,false": "STOPPED",
  "true,false": "PLAYING",
  "true,true": "PAUSED",
};

let isPlaying = false;
let isPaused = false;

const stateName = () => NAMES[`${isPlaying},${isPaused}`] ?? "not in S";

function play() {
  isPlaying = true;
  isPaused = false;
}

function pause() {
  // Nothing here asks whether there was anything to pause.
  isPaused = true;
}

function stop() {
  isPlaying = false;
  isPaused = false;
}

export default function main(): () => void {
  const step = (label: string, apply: () => void) => {
    apply();
    console.log(
      `${label.padEnd(5)} -> ${stateName().padEnd(9)}` +
        ` isPlaying=${isPlaying} isPaused=${isPaused}`,
    );
  };

  // The table says PAUSE while STOPPED is a no-op. It is the first line below.
  step("PAUSE", pause);
  step("PLAY", play);
  step("PAUSE", pause);
  step("STOP", stop);

  return () => {};
}

The first line of output is the problem. Our table says $\delta \left( \texttt{STOPPED}, \texttt{PAUSE} \right) = \texttt{STOPPED}$ -- pausing a stopped player does nothing at all. What the code does instead is set isPaused on a player that was never playing, leaving a pair of booleans that names no state in $S$ .

Nothing there is wrong in the sense the compiler cares about, and that's the point. Two booleans admit $2^2 = 4$ combinations while $|S| = 3$ , so one combination is surplus before we write a single transition. We asked for three states and built four!

That gap is where things get out of hand. Add buffering -- one more flag, one more state we genuinely meant -- and the encoding admits $2^3 = 8$ combinations for $|S| = 4$ : four unnamed states, up from one. Each flag doubles the space of things that can be true while adding a single state we wanted, so the nonsense grows as $2^k - |S|$ and the compiler stays quiet about all of it.

The fix for that particular disease is to stop spelling a state as a tuple of independent flags and name it directly:

type State = "stopped" | "playing" | "paused";

let state: State = "stopped";

function play() {
  switch (state) {
    case "stopped":
      state = "playing";
      break;
    case "paused":
      state = "playing";
      break;
      // "playing" is missing, and this still compiles.
  }
}

Now the representable states are exactly $S$ and the surplus is gone for good. But look at what happened to $\delta$ . It used to be a table we could read a row at a time; it is now smeared across one function per symbol, and the property that made the table worth trusting -- that every pair in $S \times \Sigma$ has an answer -- isn't written down anywhere any more. That missing "playing" branch is a hole in $\delta$ , and nothing reported it.

This growth is gentler than the boolean version, but it still runs the wrong way. $\delta$ owes an answer for $|S| \times |\Sigma|$ pairs: nine for the player. Add that buffering state and a $\texttt{SEEK}$ input and it's $4 \times 4 = 16$ , spread over four functions, each free to forget a state on its own. The table grows at exactly the same rate -- the difference is that a table with a hole in it looks like a table with a hole in it.

Representing this in code with XState

Both attempts went wrong in the same place: $\delta$ stopped being a thing and became a behaviour. XState hands it back. A machine is an object, the states are its keys, and each state carries its own row of the table:

Idle

import { createActor, setup } from "xstate";
import { renderMachineFlow } from "@pg/flow";

type PlayerEvent = { type: "PLAY" } | { type: "PAUSE" } | { type: "STOP" };

// δ, as data. Each state carries its own row of the table, and the four cells
// that pointed back at their own row are simply absent: a state that does not
// list an event refuses it.
const player = setup({
  types: {} as { context: Record<string, never>; events: PlayerEvent },
}).createMachine({
  id: "player",
  initial: "stopped",
  context: {},
  states: {
    stopped: { on: { PLAY: "playing" } },
    playing: { on: { PAUSE: "paused", STOP: "stopped" } },
    paused: { on: { PLAY: "playing", STOP: "stopped" } },
  },
});

export default function main(target: HTMLElement): () => void {
  const actor = createActor(player);

  // `renderMachineFlow` is this blog's diagram renderer, not part of XState. It
  // walks `states` and reads each `on` block, so every node and edge below comes
  // out of the machine above.
  const stop = renderMachineFlow(target, { machine: player, actor });

  const onClick = (event: Event) => {
    const type = (event.target as HTMLElement).dataset?.send;
    if (type === "PLAY" || type === "PAUSE" || type === "STOP") {
      actor.send({ type });
    }
  };
  target.addEventListener("click", onClick);

  return () => {
    target.removeEventListener("click", onClick);
    stop();
  };
}

Every part of the quintuple has somewhere to live:

$S$ is the set of keys under states
$s_0$ is initial
$\Sigma$ is the event union handed to setup({ types })
$\delta$ is the on block belonging to each state
$F$ is the states marked type: "final" -- none here, so $F = \emptyset$

Two of those carry weight the hand-rolled versions could not. $\Sigma$ is a type, so actor.send({ type: "SEEK" }) doesn't compile -- the alphabet is checked rather than hoped for. And $\delta$ is a single value, which is the only reason the diagram exists: the picture is not an illustration of the machine, it is rendered from it, by walking states and reading each on. Delete the $\texttt{STOP}$ line from paused, run it again, and an edge disappears!

That leaves the count. Five transitions for nine cells, and the four that are missing are exactly the self-loops. Leaving them out is deliberate: a state that doesn't list an event refuses it. Refusing is how this machine spells "ignore it", and it's a stronger claim than a self-loop -- no transition is taken at all, so the state is never exited and re-entered, and anything we later attach to entering it will not run. Press Pause while the player is stopped and the diagram doesn't so much as flicker.

Which is the part worth keeping hold of. We did not gain the nine answers by writing them out; we gained them by making $\delta$ a value again, so the four we left out are a visible absence rather than a branch nobody wrote.

Where the symbols come from

There is a question the quintuple never asks. $\delta$ is total over $S \times \Sigma$ , which is a promise about what to do with a symbol once we have it -- and nothing in $\left( \Sigma, S, s_0, \delta, F \right)$ says where symbols come from or what it costs to produce one.

So far that has been free. The symbols came from three buttons, and a button click cannot fail -- it either happened or it didn't, which is exactly why the machine looked finished. Let $\texttt{PLAY}$ mean what it means in a real player (open the stream, hand it to a decoder, start the clock), and the thing producing our symbols becomes a function that can throw:

async function play() {
  const stream = await openStream(trackId); // network: can reject
  await decoder.start(stream); //              codec: can throw
  actor.send({ type: "PLAY" });
}

Now there is no good place to put that send. Below the work, as above, and there is a window where the reader has asked to play and the machine still says $\texttt{STOPPED}$ -- so the button is live and a second press queues a second stream. Above the work, and the machine announces $\texttt{PLAYING}$ before anything is playing. Press Play below and watch which of those two the optimistic version buys:

Idle

import { createActor } from "xstate";
import { renderMachineFlow } from "@pg/flow";
import { player } from "./machine.ts";

const delay = (ms: number) => {
  const { promise, resolve } = Promise.withResolvers<void>();
  setTimeout(resolve, ms);
  return promise;
};

// Rigged to fail so the disagreement is easy to see. A real one is a fetch and a
// decoder, and its type -- Promise<Stream> -- says nothing about either failing.
async function openStream(): Promise<never> {
  await delay(400);
  throw new Error("504 from the audio host");
}

export default function main(target: HTMLElement): () => void {
  const actor = createActor(player);
  const stop = renderMachineFlow(target, { machine: player, actor });

  const log = target.querySelector<HTMLElement>("[data-log]");
  const say = (line: string) => {
    if (log) log.textContent = line;
  };

  const onClick = async (event: Event) => {
    const type = (event.target as HTMLElement).dataset?.send;
    if (type !== "PLAY" && type !== "PAUSE" && type !== "STOP") return;

    if (type !== "PLAY") {
      actor.send({ type });
      say(`${type} -> ${String(actor.getSnapshot().value)}`);
      return;
    }

    // Optimistic: the machine moves now, the actual work starts after.
    actor.send({ type: "PLAY" });
    say("opening stream...");
    try {
      await openStream();
      say("stream open");
    } catch (error) {
      // There is nowhere for this to go. Σ has no symbol for it, so δ is never
      // consulted and the diagram goes on claiming the machine is playing.
      const reason = error instanceof Error ? error.message : String(error);
      say(
        `${reason} -- but the machine still says ${
          String(actor.getSnapshot().value)
        }`,
      );
    }
  };
  target.addEventListener("click", onClick);

  return () => {
    target.removeEventListener("click", onClick);
    stop();
  };
}

The diagram is wrong and stays wrong. It isn't a bug in $\delta$ -- $\delta$ was never consulted, because the failure never became a symbol. Two booleans let us reach a state that no element of $S$ named; a rejected promise is a transition that no element of $\Sigma$ names. Same hole, one axis over. And note that the machine did not refuse the failure, which would at least have been an answer. It never heard about it.

The FSM can be taught about this, and it should be. Add a $\texttt{LOADING}$ state, add $\texttt{OPENED}$ and $\texttt{FAILED}$ to $\Sigma$ , and the lie becomes unrepresentable: nothing can claim to be playing until the stream says so. That is the formalism working. It is also $|S| \times |\Sigma|$ doing what it does -- four states and five symbols is twenty answers owed, up from nine -- and every further failure mode we care to distinguish is another symbol multiplied across every state.

The arithmetic is fine; we signed up for it. What isn't fine is that nothing made us do it. openStream has type (id: string) => Promise<Stream>, and that type is silent about the 504, about the codec, about every other way it can end. We named $S$ and we named $\Sigma$ , and the failures are still anonymous -- so the compiler cannot tell us we forgot $\texttt{FAILED}$ , any more than it told us about the missing "playing" branch.

There is a second thing that type is quiet about. If the reader presses Stop while the stream is still opening, the work carries on and eventually reports back -- and neither $\delta$ nor openStream knows the difference between "the stream opened" and "the stream opened, but nobody wants it now".

What we're missing is a way to describe the work that produces symbols with the same rigour we used on the machine: what it needs, what it yields, what it can fail with, and whether it can be called off -- all in the type, where forgetting one is a compile error rather than a silent hole. That is the gap Effect.ts fills.

A primer on Effect

Effect is a big library with a small idea at the bottom of it, and the small idea is the only part we need. An Effect<A, E, R> is a description of a program: it yields an A, it can fail with an E, and it needs an R to run. Building one runs nothing. It is a value, in the way a recipe is a value and a cooked dinner is not.

Compare that to the thing we had. A Promise<Stream> is already running by the time we are holding it, and it has exactly one type parameter: the happy one. How it fails is not written down, because JavaScript has never had a way to write it down -- throws is not part of a signature. Effect's middle parameter is that missing half of the type.

Idle

import { Data, Duration, Effect, Fiber, Schedule } from "effect";

// A failure with a name. This is the whole trick: the ways this can go wrong are
// values in a union, not an anonymous `throw` somewhere down the call stack.
class StreamFailed extends Data.TaggedError("StreamFailed")<{
  readonly status: number;
}> {}

let attempts = 0;

// A *description* of a program, not a running one. The type says all three
// things at once: it yields a string, it can fail with StreamFailed, and it
// needs nothing from its environment.
const openStream: Effect.Effect<string, StreamFailed> = Effect.gen(
  function* () {
    yield* Effect.sleep(Duration.millis(120));
    attempts += 1;
    console.log(`GET /track/42 (attempt ${attempts})`);
    return attempts < 3
      ? yield* Effect.fail(new StreamFailed({ status: 504 }))
      : "stream#42";
  },
);

// Still a description. Retrying and handling are just more description, built by
// composing values -- no request has been made yet.
const program = openStream.pipe(
  Effect.retry({
    schedule: Schedule.exponential(Duration.millis(40)),
    times: 3,
  }),
  Effect.tap((stream) => Effect.sync(() => console.log(`opened ${stream}`))),
  // Until StreamFailed is handled it stays in the error channel, and the
  // compiler keeps bringing it up. Handle it and the channel becomes `never`.
  Effect.catchTag(
    "StreamFailed",
    (error) =>
      Effect.sync(() => console.error(`gave up: HTTP ${error.status}`)),
  ),
);

export default function main(): () => void {
  console.log("nothing above has run");

  // The only line that touches the world.
  const fiber = Effect.runFork(program);

  return () => {
    Effect.runFork(Fiber.interrupt(fiber));
  };
}

Two things in there are worth pointing at. The first is that openStream and program are just definitions -- the retry policy and the error handling are built by composing values, and the log line proves nothing has happened yet. Nothing actually touches the world except the Effect.runFork line, at the edge, once. That is the ordinary functional trade: keep the middle of the program pure and push the effects out to a boundary you can point at.

The second is Data.TaggedError. It gives a failure a _tag, which makes the ways a program can go wrong into a discriminated union -- something we can enumerate, match on, and be told about when we miss a case. Effect.catchTag takes one member out of that union, and until every member is handled the E channel is not empty and the compiler will keep saying so.

Which is exactly the sentence the last section was missing. Our failures were anonymous, and a symbol is nothing more than a name. Give the failures names and they can be symbols!

Errors as symbols

So let's do what we said. $\texttt{LOADING}$ joins $S$ , $\texttt{OPENED}$ and $\texttt{FAILED}$ join $\Sigma$ , and the two channels of the Effect are wired to the two new symbols:

const load = openStream.pipe(
  Effect.andThen((stream) => Effect.sync(() => actor.send({ type: "OPENED" }))),
  Effect.catchTag(
    "StreamFailed",
    (error) =>
      Effect.sync(() =>
        actor.send({ type: "FAILED", reason: `HTTP ${error.status}` })
      ),
  ),
);

That is the whole integration, and the important part is what its type says. openStream could fail with StreamFailed; load cannot fail at all. Handling the tag emptied the error channel, so load has type Effect<void, never> -- there is no remaining way for this work to finish that the machine has not been told about. $\delta$ was total over $S \times \Sigma$ all along; what changed is that $\Sigma$ now covers everything that can actually happen!

Idle

import { createActor } from "xstate";
import { Effect, Fiber } from "effect";
import { renderMachineFlow } from "@pg/flow";
import { player } from "./machine.ts";
import { openStream } from "./stream.ts";

export default function main(target: HTMLElement): () => void {
  const actor = createActor(player);
  const stop = renderMachineFlow(target, { machine: player, actor });

  const log = target.querySelector<HTMLElement>("[data-log]");
  const say = (line: string) => {
    if (log) log.textContent = line;
  };

  // Both outcomes become symbols the machine already knows. Once StreamFailed is
  // handled the error channel is `never` -- there is no longer a way for this
  // work to finish that δ has not been asked about.
  const load = openStream.pipe(
    Effect.andThen((stream) =>
      Effect.sync(() => {
        say(`opened ${stream}`);
        actor.send({ type: "OPENED" });
      })
    ),
    Effect.catchTag("StreamFailed", (error) =>
      Effect.sync(() => {
        say(`HTTP ${error.status} -- reported as FAILED`);
        actor.send({ type: "FAILED", reason: `HTTP ${error.status}` });
      })),
  );

  let fiber: Fiber.RuntimeFiber<void, never> | null = null;
  const callOff = () => {
    if (!fiber) return;
    Effect.runFork(Fiber.interrupt(fiber));
    fiber = null;
  };

  const onClick = (event: Event) => {
    const type = (event.target as HTMLElement).dataset?.send;
    if (
      type !== "PLAY" && type !== "PAUSE" && type !== "STOP" && type !== "RETRY"
    ) return;

    const before = actor.getSnapshot().value;
    actor.send({ type });
    const after = actor.getSnapshot().value;

    if (after === before) {
      say(`${type} refused in ${String(before)}`);
      return;
    }
    if (after === "loading") {
      say("opening stream...");
      fiber = Effect.runFork(load);
    }
    // Leaving `loading` by pressing Stop calls the request off -- the
    // cancellation the last section had no way to express.
    if (after === "stopped") {
      callOff();
      say("stopped, request cancelled");
    }
  };
  target.addEventListener("click", onClick);

  return () => {
    target.removeEventListener("click", onClick);
    callOff();
    stop();
  };
}

Press Play. The machine goes to $\texttt{LOADING}$ and stays there -- it no longer claims to be playing something that has not loaded. That first attempt is rigged to fail, so a moment later the red node lights up, because $\texttt{FAILED}$ arrived and $\delta$ had an answer for it. Retry goes round again and succeeds. Nothing lies at any point, and no state in the diagram is one we invented to hold a mistake.

Note where the HTTP status went. It is in context, not in the state: there is one $\texttt{FAILED}$ state, not one per status code. States are for the shape of the machine, context is for the data it carries -- the same split that stopped two booleans from turning into four states.

The other silence is closed too. Effect.runFork hands back a fiber, so pressing Stop while the stream is still opening interrupts it. The request is called off rather than left to land later and be ignored, which means there is no window where a stale success can arrive and argue with the state we are now in.

A player worth shipping

Three states was enough to make the argument, but not enough to be a player: real ones stall in the middle of a track, seek, reach the end, and fail. Adding those takes $S$ to seven and $\Sigma$ to ten:

Idle

import { createActor } from "xstate";
import { Effect, Fiber } from "effect";
import { renderMachineFlow } from "@pg/flow";
import { player, type PlayerValue } from "./machine.ts";
import { openStream, refill } from "./stream.ts";

const SENDABLE = [
  "PLAY",
  "PAUSE",
  "STOP",
  "SEEK",
  "STALL",
  "ENDED",
  "RETRY",
] as const;

const isSendable = (
  value: string | undefined,
): value is typeof SENDABLE[number] =>
  SENDABLE.some((allowed) => allowed === value);

export default function main(target: HTMLElement): () => void {
  const actor = createActor(player);

  const log = target.querySelector<HTMLElement>("[data-log]");
  const say = (line: string) => {
    if (log) log.textContent = line;
  };

  const onOpened = openStream.pipe(
    Effect.andThen((stream) =>
      Effect.sync(() => {
        say(`opened ${stream}`);
        actor.send({ type: "OPENED" });
      })
    ),
    Effect.catchTag(
      "StreamFailed",
      (error) =>
        Effect.sync(() =>
          actor.send({ type: "FAILED", reason: `HTTP ${error.status}` })
        ),
    ),
  );

  const onRefilled = refill.pipe(
    Effect.andThen(Effect.sync(() => {
      say("buffer refilled");
      actor.send({ type: "RESUMED" });
    })),
  );

  // The work each state sets in motion: a total function from S, all over again.
  // `Record` demands every key, so adding a state to the machine stops this
  // compiling until we have said what it starts -- including when the honest
  // answer is "nothing at all".
  const workFor: Record<PlayerValue, Effect.Effect<void>> = {
    stopped: Effect.void,
    loading: onOpened,
    playing: Effect.void,
    buffering: onRefilled,
    paused: Effect.void,
    ended: Effect.sync(() => say("track ended")),
    failed: Effect.sync(() =>
      say(`failed: ${actor.getSnapshot().context.reason}`)
    ),
  };

  let current: PlayerValue | null = null;
  let fiber: Fiber.RuntimeFiber<void, never> | null = null;

  // Subscribed before the diagram starts the actor, so the initial state is seen.
  const subscription = actor.subscribe((snapshot) => {
    if (snapshot.value === current) return;
    current = snapshot.value;
    // Leaving a state calls off whatever that state had started.
    if (fiber) Effect.runFork(Fiber.interrupt(fiber));
    fiber = Effect.runFork(workFor[snapshot.value]);
  });

  const stop = renderMachineFlow(target, { machine: player, actor });

  const onClick = (event: Event) => {
    const type = (event.target as HTMLElement).dataset?.send;
    if (!isSendable(type)) return;
    const before = actor.getSnapshot().value;
    actor.send({ type });
    if (actor.getSnapshot().value === before) {
      say(`${type} refused in ${String(before)}`);
    }
  };
  target.addEventListener("click", onClick);

  return () => {
    target.removeEventListener("click", onClick);
    if (fiber) Effect.runFork(Fiber.interrupt(fiber));
    subscription.unsubscribe();
    stop();
  };
}

Seventy cells, eighteen of them written down. The other fifty-two are refusals, and they are refusals we can see: the diagram has no edge for $\texttt{STALL}$ out of $\texttt{PAUSED}$ because a paused track cannot run out of buffer.

Notice a distinction that the boolean version could not have kept. Stalling and pausing both stop the audio, and they are not the same thing -- one is the network's fault and one is the listener's decision, they exit on different symbols, and only one of them should light the play button back up. Two flags would have smeared them into !isPlaying and left the difference in a comment.

At this size a second kind of hole opens up, though. It is no longer only $\delta$ that owes an answer for every case: every state also has to say what work it sets in motion. Which is a total function from $S$ again, so it can be written as one:

const workFor: Record<PlayerValue, Effect.Effect<void>> = {
  stopped: Effect.void,
  loading: onOpened,
  playing: Effect.void,
  buffering: onRefilled,
  paused: Effect.void,
  ended: Effect.sync(() => say("track ended")),
  failed: Effect.sync(() => say(`failed: ${reason()}`)),
};

Record<PlayerValue, ...> demands every key, so adding an eighth state stops this compiling until we have said what it starts. And Effect.void, "nothing at all", is a perfectly good answer that we still had to write. That is the self-loop lesson one layer out: the value of totality is not that every answer is interesting, but that no answer is missing.

Being a table of values rather than a pile of callbacks is what makes it a table at all, incidentally. An Effect is inert, so the work each state starts can sit in a Record and be looked up -- which is only possible because building one does nothing. Cancellation then falls out of the lookup: leaving a state interrupts whatever that state started, so seeking away from a load does not race with it.

Where this pays off

Four moves, and each one turns a class of bug into a compile error. Name the states, so nonsense combinations stop being representable. Do the same for the symbols, so the events are checked rather than hoped for. Keep $\delta$ a value, so the holes in it stay visible. Put the failure modes in the type, so they become symbols and $\delta$ has to answer them.

A media player is a bad advertisement for all of this, because you can hold it in your head. The technique starts paying at exactly the point where you cannot.

What I actually reach for it for at work is conditional form validation, which is a state machine wearing a very convincing disguise. A form is editing, then validating, then invalid or submitting, then rejected or submitted, and the events are the things a person does to it. The boolean-soup failure mode is endemic there: isDirty, isValidating, hasErrors, isSubmitting, submitFailed is five flags and $2^5 = 32$ combinations, of which about six mean anything, and "can this be submitted?" ends up as a conjunction that nobody can audit and everybody is slightly afraid of.

Conditionals are where $\delta$ earns its keep. Which fields matter depends on answers given earlier -- pick a business account and three new fields become required, or pick a country and the postcode rule changes underneath you. As guards on transitions, those rules are one object you can read top to bottom, and a reviewer can be handed the diagram and asked whether it looks right. But as if statements spread across change handlers, the rules do not exist in any one place at all, and the only way to find out what the form does is to run it.

Then the async ones make it the previous problem exactly. Checking whether an email is taken, whether an address resolves, whether a discount code is live: all of them are functions that emit transition inputs and can fail, and their failure modes are genuinely different. "This value is taken" and "the service is down" want different states, different messages, and different retry behaviour. Untyped, they collapse into one catch that puts a red border on a field and tells the user to try again. Typed, they are separate symbols, and $\delta$ has to have something to say about each of them.

And cancellation stops being an afterthought. Someone keeps typing while a uniqueness check is in flight; the check for what they typed four keystrokes ago resolves and paints an error for a value that no longer exists. That bug is everywhere, and it is the same bug as a stale stream landing after Stop. Fork the check, interrupt it when the field changes, and the stale answer never arrives to argue.

None of which comes free. Both libraries have a real learning curve, and the machine will try to become a god object if you let it -- the discipline is to keep the shape in states and the data in context, and to stop when the shape is described. A login form with two fields does not need any of this, and reaching for it there is how the pattern earns a bad name.

But there is nothing new in it. It is the same quintuple from the top of this post, taken literally instead of admiringly: a finite set of states, a finite alphabet of things that can happen, and one function that has an answer for every pair. The libraries are just the part that makes the compiler hold us to it.
